Milwaukee 2217-20 Digital Multimeter Review
Milwaukee 2217-20 Digital Multimeter Feature
- Wide Voltage range to 600 AC /DC volts
- Auto Range to millivolts
- True-RMS for accurate measurement in all applications
- Lo-Z measurement to eliminate ghost voltage
- High Contrast, White on Black Display
With its simple yet rugged design, the Milwaukee 2217-20 Digital Multimeter offers a wide voltage range and a best-in-class display for easy readings. Ideal for use by residential, commercial, and industrial electricians, as well as service and HVAC/R technicians, the 2217-20 is part of Milwaukee's Test & Measure line of professional tools. This digital multimeter covers 95 percent of general testing applications and offers complete, targeted features to handle even the most demanding jobs.
 | | 2217-20 Digital Multimeter | | TRMS | Yes | | Safety Rating | CAT III 600 V | | Voltage AC | 6.00 mV - 600 V | | Voltage DC | 600.0 mV - 600 V | | Lo-Z Measurement | Yes | | Frequency | 10 Hz - 50.00 kHz | | Resistance | 40 MOhm | | Continuity | Audible | | Capacitance | 1000 µF | | Current AC/DC | 10.00 A | | Contact Temperature | -40 to 752°F
(-40 to 400°C) | | Display Backlight | Yes | | Display Type | White on Black LCD | | HOLD/MIN/MAX | Yes | | Bargraph | Yes | | Non-contact Voltage | Accessory | | Rugged over-molding | Yes | | Battery | 2 x AA Alkaline Batteries | | Length | 6.5" |
|  |
|
The big display is clear and easy to read. View larger. |
Durable True-RMS Meter with High Voltage Range for Professional UseThe 2217-20 is a heavy-duty True-RMS meter that' s perfect for a range of professional applications involving security systems, electrical equipment, motor drives, controllers, and more. It boasts all the high-performance features you need to get your job done-out in the field, on the jobsite, or in the plant. This meter offers frequency measurements from 10Hz to 50kHz, contact temperature measurements from -40 to 762 degrees Fahrenheit, and current measurement to 10A AC/DC.
In addition, the 2217-20 provides thermocouple (dual banana) input for contact-temperature measurement, a hold function, a min/max function, and a digital bar-graph readout. Rated CAT III 600V for safety with a capacitance to 1,000 microfarads, it also includes an on-board accessory mount for a voltage detector or magnet (sold separately).
A side-mounted dial allows for one-handed use. View larger. |
The 2217-20 boasts a durable, straightforward design, a simple user interface, and a full set of features for electricians and HVAC technicians. A side-mounted dial allows for one-handed use and Lo-Z measurement eliminates ghost voltage. At the same time, a high-contrast, white-on-black display with backlight makes this tool perfect for even the darkest conditions.
The 2217-20 is backed by a five-year limited manufacturer's warranty.
Test & Measure Tools: Inspect, Detect, and Access with Best-in-Class Features
Launched in 2009, Milwaukee's Test & Measure line features trade-specific tools designed to meet the demands of professional users, including electricians, HVAC/R technicians, builders, and remodelers. These innovative, battery-powered tools boast user-friendly, compact designs that stand up to rough-and-tough jobsites.
Test & Measure tools also provide a range of best-in-class features for utility and productivity. Many of the units are available as separate models with features that are specifically tailored to the needs of electricians and HVAC/R technicians.
About the Milwaukee Electric Tool Corporation
In 1924 Milwaukee Electric Tool introduced the Hole-Shooter, the first lightweight, portable, one-handed 1/4-inch-capacity drill, and the company has been dedicated to producing innovative, heavy-duty electric power tools that meet the needs of professional users ever since.
Milwaukee's product line has grown to include more than 500 tools and over 3,500 accessories. The company uses state-of-the-art technologies and sophisticated manufacturing techniques to ensure that quality is built into each of its tools, resulting in durable and reliable professional products.
What's in the Box
Digital Multimeter; one test lead set (red and black); one thermocouple (dual banana); two 'AA' batteries; and manual.
The Milwaukee Digital Multimeter is a heavy-duty True-RMS meter for professional residential, commercial and industrial applications, plus it's the perfect tool for the professional electrician. Application: Electrical and HVAC, Display Shows: Bargraph, Functions (qty.): 10, DC Volts: 600mV - 600V, AC Volts: 6.00mV - 600V, Amps: 10, UL Listed: Yes
